ТИП УСТРОЙСТВА --- МАРШРУТИЗАТОР
ТИП МОДЕМА --- GSM/3G/4G
БАЗОВАЯ СКОРОСТЬ ПЕРЕДАЧИ ДАННЫХ --- 10/100 МБИТ/С
КОЛИЧЕСТВО LAN-ПОРТОВ --- 4
WAN-ПОРТ --- ETHERNET 10/100/1000 МБИТ/СЕК
ЧИСЛО ПОДДЕРЖИВАЕМЫХ VPN-ТУННЕЛЕЙ --- 20
ОБЪЕМ ОПЕРАТИВНОЙ ПАМЯТИ --- 1024 МБ
СЕТЕВЫЕ СТАНДАРТЫ --- IEEE 802.1Q (VLAN), IEEE 802.1P (PRIORITY TAGS), IEEE 802.1D (SPANNING TREE), IEEE 802.1X

Технические характеристики
Brand Cisco
Model C819HG-U-K9
Device Type Router - wireless cellular modem - 4-port switch (integrated)
Enclosure Type Desktop - modular
Cellular Protocol GPRS, UMTS, EDGE, HSDPA, HSPA
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet
Capacity Connection / user qty : 20
Network / Transport Protocol L2TP, IPSec, DHCP, L2TPv3, DDNS
Routing Protocol OSPF, IS-IS, RIP-1, RIP-2, BGP, EIGRP, HSRP, DVMRP, VRRP, NHRP, static IP routing, IGMPv3, GRE, static IPv4 routing, static IPv6 routing, policy-based routing (PBR), WCCP, Bidirectional Forwarding Detection (BFD)
Remote Management Protocol SNMP 2, SNMP 3, HTTP, SSH, CLI
Compliant Standards IEEE 802.1D, IEEE 802.1Q, IEEE 802.1x
Power AC 120/230 V ( 50/60 Hz )
Dimensions (WxDxH) 19.6 cm x 20.6 cm x 4.4 cm
Weight 1.5 kg
Manufacturer Warranty 1 year warranty
GENERAL ---
Device Type Router - 4-port switch (integrated)
Enclosure Type Desktop - modular
Connectivity Technology Wireless, wired
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet
Capacity Connection / user qty : 20
Network / Transport Protocol L2TP, IPSec, DHCP, L2TPv3, DDNS
Routing Protocol OSPF, IS-IS, RIP-1, RIP-2, BGP, EIGRP, HSRP, DVMRP, VRRP, NHRP, static IP routing, IGMPv3, GRE, static IPv4 routing, static IPv6 routing, policy-based routing (PBR), WCCP, Bidirectional Forwarding Detection (BFD)
Remote Management Protocol SNMP 2, SNMP 3, HTTP, SSH, CLI
Encryption Algorithm DES, Triple DES, 128-bit AES, 192-bit AES, 256-bit AES
Authentication Method RADIUS, TACACS+
Features Firewall protection, VPN support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, traffic shaping, MAC address filtering, IPv6 support, Low-latency queuing (LLQ), Class-Based Weighted Fair Queuing (CBWFQ), Weighted Fair Queuing (WFQ), Spanning Tree Protocol (STP) support, Access Control List (ACL) support, Quality of Service (QoS), DHCP server, Virtual Route Forwarding-Lite (VRF-Lite), DNS proxy, DHCP relay, DHCP client
Compliant Standards IEEE 802.1D, IEEE 802.1Q, IEEE 802.1x
RAM 512 MB (installed) / 512 MB (max)
Flash Memory 256 MB (installed) / 256 MB (max)
Status Indicators Status, signal strength
COMMUNICATIONS ---
Type Wireless cellular modem
Cellular Protocol GPRS, UMTS, EDGE, HSDPA, HSPA
Max Transfer Rate 7.2 Mbps
EXPANSION / CONNECTIVITY ---
Interfaces WAN : 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45Serial : 1 x consoleManagement : 1 x console - mini-USB Type BSerial : 1 x auxiliary - RJ-45LAN : 4 x 10Base-T/100Base-TX - RJ-45
Expansion Slot(s) 2 (total) / 2 (free) x SIM card
AERIAL ---
Aerial External detachable
Antenna Qty 2
POWER ---
Power Device Power adapter - external
Voltage Required AC 120/230 V ( 50/60 Hz )
Power Consumption Operational 11 Watt
MISCELLANEOUS ---
Width 19.6 cm
Depth 20.6 cm
Height 4.4 cm
Weight 1.5 kg
MTBF 400,000 hour(s)
Compliant Standards CISPR 24, EN 61000-3-2, EN55022, ICES-003, IEC 61000-3-3, IEC 61000-4-11, EN55024, CISPR 22, EN 61000-6-1, EN 301.489.1, ANSI/UL No. 1459, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, EN 61000-4-5, FCC CFR47 Part 15, EN300-386, IEC 60950-1, UL 60950-1 Second Edition, EN 301.489.7, EN 301.489.24, EN 301.511, MIL-STD 810G, BSMI CNS 13438, EN 301.908, CAN/CSA C22.2 No. 60950-1, VCCI V-3
