Number of inputs:
Phono (2 mV / 47 kOhm / 32 dB) (DIN connector).
Aux (DIN connector)
Tuner (200 mV / 470 kOhm / 26 dB) (DIN connector)
Tape 200 mV / 470 kOhm / 26 dB) (DIN connector).
Number of outputs:
Tape Rec 1, 2: 200 mV, 2.2 kOhm.
Tape Rec DIN: 40 mV, 80 kOhm
Headphones (6.3mm jack): 8 - 200 Ohm
2 speaker pairs: 4 - 8 Ohm (A: terminal; B: DIN connector)

Technical Data

Continuous power (at distortion).
8 Ohm:
4 Ohm: 2x 40 W
Dynamic power
8 Ohm:
4 Ohm: 2x 60 W
Total harmonic distortion: 0.1 %
Dämpfungsfaktor: >35 at 40 Hz
Frequency response: 10 - 40'000 Hz
Signal-to-noise ratio:
> 70 dB at 1 kHz
Stereo channel separation:
> 55 dB at 1 kHz
> 35 dB at 10 kHz
Tone control:
Bass: ± 12 dB at 40 kHz
Treble: ± 12 dB at 15 kHz

Loudness: Yes
High Filter: Yes
Low Filter (Subsonic): No
Mute:
